Repeater City - Heat Maps


Interactive Repeater Map
Click on Frequency for Talkgroup Deck

Talkgroups  /  TG Viewer
Click on Color Code for Rptr Admin Email

User Radio Rx Freq
User TX Offset
Color Code / Contact
Best Practices

BCBC - Blackcomb Mtn. -Whistler - BCBBC-TRBO Affiliate VE7WRP 2,200 meters, 15 watts443.8500 +5Mhz
CC2
BCBC - Nanaimo -Nanaimo - BCNBC-TRBO Affiliate VE7NHR 440.8250 +5Mhz
CC1
BCBC - New Westminster -New Westminster - BCWBC-TRBO Affiliate VE7NWR 444.6000 +5Mhz
CC1
BCBC - North Vancouver -Mt. Seymour - BCSBC-TRBO Affiliate VE7RAG Wide area coverage; South to Bellingham443.4000 +5Mhz
CC1
BCBC - Port Alberni -Port Alberni - BCPBC-TRBO Affiliate VE7CIM 444.2500 +5Mhz
CC1
BCBC - Squamish -Squamish - BSQBC-TRBO Affiliate VA7WRP 443.8500 +5Mhz
CC3
BCBC - UBC -University BC - BCUBC-TRBO Affiliate VE7RYS 442.1750 +5Mhz
CC1
BCBC - West Vancouver -Ambleside - BCABC-TRBO Affiliate VA7BC low level, 25 watts443.8500 +5Mhz
CC1
CACA - Santiago Pk -Santiago Pk KA6P Orange County, CA // Very wide area coverage throughout Southern California / IRG affiliate449.0375 -5Mhz
CC1
CACA - Wrightwood -Wrightwood KA6P Wrightwood CA / High ASL but localized coverage / IRG Affiliate449.0375 -5Mhz
CC2
IDCoeur d'Alene ID -Blossom Ridge - CDA I-90 corridor coverage, about 69 miles from 4th of July Pass ID to Four Lakes WA (Hwy 904), north to Sagle440.9250 *+5Mhz
CC1 - BP
IDCoeur d'Alene ID -Coeur d'Alene Metro - CDMLocal area surrounding CdA; Post Falls, Rathdrum, Hayden, S. to Driftwood Bay, E. to Regan Ranch Airport 146.4500 +1Mhz
CC1
IDLewiston ID -Craig Mtn. - LEW4800 feet ASL, ~50 mile coverage Installed 07-26-20442.1000 +5Mhz
CC1
IDSaint Joseph ID -Saint Joe Baldy - SJBKB7SIJ Wide area coverage area in Eastern Idaho / 6-8-24: On the Air and Network / On same pair as St Maries443.7500 +5Mhz
CC1
IDSaint Maries ID -Town Center - SAIInstalled and on network in Town Center, high site (5,800 ASL) installation in September 2022 / On same pair as St Joseph443.7500 *+5Mhz
CC1
ORBend OR -Powell Butte - BPBW7GXJ Repeater is at low level for testing, Bend coverage and part of Batchlor Ski Area Installed 03-22-23440.9375 +5Mhz
CC1
ORBiggs Junction OR -Juniper Point - BIJI-84 Group This wide-area repeater covers the I-84 corridor from Celilo Village to Boardman Oregon, Goldendale Washington and portions of Gilliam, Sherman, Morrow, Wasco Counties in Oregon and Klickitat County in Washington443.3250 *+5Mhz
CC1
ORBoardman OR -Golgotha Butte - BOGI-84 Group This wide-area repeater covers the I-84 corridor from Arlington to approximately 8 miles west of Pendleton Oregon, sections of Washington State Route 14 from Roosevelt Washington to US Highway 395.443.3750 +5Mhz
CC1
ORCascades Locks OR -Cascades Locks - CAHI-84 Group I-84 Columbia River Gorge coverage Corbett (Sandy River) to Wyeth, OR (MP 51). SR 14 Clark/County line to Home Valley, WA, Cascade Locks, OR, Carson and Stevenson, WA443.3250 *+5Mhz
CC1
ORCorbett OR -Lookout Point - COLI-84 Group Wide-area, I-5 corridor coverage Salem, OR to Kalama, WA. I-84 corridor coverage Portland, OR to Bridal Veil, OR. Highway 26 coverage Portland to Rhododendron, OR. Portland & Vancouver, WA, Multnomah and portions of Clackamas, Columbia, Marion, Washington and Yamhill, Clark and portions of Skamania County, WA. Installed 11-08-19443.1000 +5Mhz
CC1
ORDallas OR -City View - DCVN7MAQ Dallas coverage. Polk County EOC indoor coverage.442.8875 +5Mhz
CC1
ORGresham OR -Hospital - GRHI-84 Group Gresham area & East Multnomah County Installed 08-02-19443.0750 *+5Mhz
CC1
ORHillsboro OR -Saddle Mtn - HISI-84 Group - ARRG joint project; Wide-area, Covers the five county Portland Metro Area, including portions of Benton, Clatsop, Linn, Marion, Polk and Tillamook, counties in Oregon, and portions Cowlitz, Pacific and Wahkiakum counties in Washington and major portions of Interstate 5 from approximately Milepost 27 near Kalama, Washington to Milepost 209 near Harrisburg, Oregon. Installed 06-23-21 Installed 06-23-21440.8125 +5Mhz
CC1
ORHood River OR -Burdoin Mtn. - HOBI-84 Group This repeater covers the Interstate 84 corridor within the Columbia River Gorge between Wyeth and The Dalles Oregon and along Washington State Route 14 from Cook to Dallesport Washington443.0750 *+5Mhz
CC1
ORHood River OR -Mount Defiance - HODI-84 Group N7LF This wide-area repeater covers portions of the I-84 corridor from Portland to Biggs Junction, Oregon Route 35, multiple Oregon and Washington Counties, and the Gifford Pinchot and Mount Hood National Forest backcountry. Installed 08-04-23 Installed 08-05-23443.0875 +5Mhz
CC1
ORManzanita OR -Manzanita - MNZN5GB Low level, Manzanita area, south to Smith Lake, North to Elk Flats440.2250 +5Mhz
CC1
ORMt. Hood OR -Government Camp - MHGI-84 Group ARRG - joint project; This wide-area coverage repeater is presently using a temporary directional antenna that favors Eastern Oregon, including mobile coverage on Highway 26 that begins approximately East of Rhododendron and portions of Highway 97 to Bend, Oregon. Installed 06-29-21444.1500 +5Mhz
CC1
ORPine Hollow OR -Pine Hollow - PNHI-84 Group I-84 Group - Pine Hollow Reservoir Recreational Area. Installed 06-15-23444.8375 +5Mhz
CC1
ORPortland OR - Mt Scott -Mount Scott - POMI-84 Group Wide-area, I-5 corridor coverage Salem, OR to Longview, WA. I-84 corridor coverage Portland, OR to Corbett, OR. Highway 26 coverage Banks to Brightwood, OR. Portland; Vancouver, WA, Multnomah and portions of Clackamas, Marion, Washington and Yamhill; Clark County, WA. Installed 08-02-19441.3250 +5Mhz
CC7
ORPortland OR - PPMC -PPMC - POPSW Wash and E. Portland Metro444.8375 +5Mhz
CC7
ORPortland OR - Westhills -Westhills - POSI-84 Group ARRG joint project; Wide-area, I-5 corridor coverage Salem, OR to Longview, WA. I-84 corridor coverage Portland, OR to Bridal Veil, OR. Highway 26 coverage West of Buxton to Cherryville, OR. Portland and Vancouver, WA, Multnomah and portions of Clackamas, Marion, Washington and Yamhill & Clark County, WA. Installed 12-26-19440.5125 +5Mhz
CC1
ORPrineville OR -Town Center - PRTInstalled at Town Center and On-network as of 9-21-21441.2500 +5Mhz
CC1
ORSalem OR -Popcorn Hill - SLP K7LWV Willamette Valley coverage145.3500 -0.6Mhz
CC1
ORSalem OR -Prospect Hill - SPHSRA repeater W7SRA Willamette Valley coverage Installed 01-29-21441.2750 +5Mhz
CC1
ORThe Dalles OR -Stacker Butte - THSI-84 Group Wide-area, I-84 corridor coverage Hood River, OR to Biggs Junction, OR. The Dalles, OR and Goldendale, WA. 443.1000 +5Mhz
CC1
WAAriel WA -Ariel VHF - ARAGround mounted pole and new 3dB antenna in June 2022, network testing currently147.4125 *-1Mhz
CC1 - BP
WABellevue WA -Cougar UHF - BVCI-5 corridor N9VW Wide area coverage; Tacoma to Everett441.2875 +5Mhz
CC1
WABellevue WA -Cougar VHF - BVV 9-24-22: Repeater replaced, back in service / Wide area coverage; Tacoma to Everett147.0200 +0.6Mhz
CC1 - BP
WABellingham WA-UHF -Lookout Mtn UHF - BEUI-5 corridor Wide area coverage; Everett to Vancouver BC // 11-24-23: IP Network is back to normal operation440.9250 *+5Mhz
CC1 - BP
WABellingham WA-VHF -Lookout Mtn VHF - BEVI-5 corridor Wide area coverage, joint project with the Mt Baker Radio Club146.5000 *+1Mhz
CC1 - BP
WABrush Prairie WA -Clark Range - BPCService area: SW Washington, East Portland and East Multnomah County. East along I-84 to approx Corbett, West along Columbia River to Scappoose. 444.1125 +5Mhz
CC7
WACathlamet WA -Wahkiakum HS - CWMN7WAH Low level / Hwy 4 coverage / At perm site and project completed 3-26-24 Installed 03-08-24146.4500 +1Mhz
CC1
WAChehalis WA -BawFaw Mtn - CHBI-5 corridor 10-14-23: New repeater installed, new ant installed 10-19-23 / Wide area, Portland OR to Tacoma WA / Astoria OR to north of Ocean Shores WA146.5000 *+1Mhz
CC1 - BP
WAEllensburg WA-VHF -SunEast VHF - ELV I-90 from Easton to Vantage and parts East of Vantage, well South of Ellensburg toward Yakima147.4125 *-1Mhz
CC1 - BP
WAEphrata WA -Beasley Hill - EPB Moses Lake and I-90 from West of Vantage to East of Ritzville, North to Coulee City, South past Royal City and Othello, joint effort by the Central Washington ARC, KC7AAD and PNWDigital.Net Installed 11-16-19147.4125 *-1Mhz
CC1 - BP
WAIssaquah WA -E Tiger Mtn UHF - ITUWide area coverage of I-90, I-405 and I-5442.0250 +5Mhz
CC1
WAIssaquah WA -E. Tiger Mtn VHF - ITVInstalled 5-2-23 / Wide area coverage of I-90 east to Bandera, I-405 and I-5, including Seattle, Hobart, Snoqualmie & N. Bend146.8750 -0.6Mhz
CC1
WAKelso WA -Columbia Heights - KEC Columbia Heights North side, On-Air 3-17-18 and on network 3-24-18444.7125 +5Mhz
CC1
WALind WA -Lind Hill - LHVTo Be installed 11-5-23 // I-90 from Vantage to Ritzville // Same pair as Krell VHF and Ellensberg VHF147.4125 *-1Mhz
CC1 - BP
WALongview WA -Rainier Hill OR - LVRI-5 corridor Wide area, Portland, OR to Napavine, WA441.7000 +5Mhz
CC1
WAMazama WA -Fawn Creek - MAZMobile coverage in the North Methow Valley; Hwy 20 from west of Washington Pass to Twisp145.2100 +2.78Mhz
CC3 - BP
WAMazama WA -Grizzley - MAGLow Level, low power for local fill-in area coverage444.8500 +5Mhz
CC3
WANaneum Ridge -Naneum Ridge VHF - NMRVery wide coverage repeater, in service and operating well, including Moses Lake, down toward Tri-Cities, Wenatchee, Waterville, Mansfield Installed 05-22-08146.4875 +1Mhz
CC1
WAOcean Shores -Town Center - OCSWA7DMR , Installed 5-11-2021, now on new antenna and Heliax at 30 feet, low level repeater, coverage potentially Westport to Ocean City and east to Aberdeen146.4125 +1Mhz
CC1 - BP
WAPalouse WA -Kamiak - PAKN7LL 4-3-24: Installed, on air on network; New antenna pending installation for better coverage into Colfax, Palouse, Pullman, Moscow coverage444.1500 +5Mhz
CC1
WAProsser WA -Horse Haven - PHHN7QNM I-82/Hwy 22 Coverage from Tri-Cities to Yakima, likely to Walla, Hermiston and Boardman, installed 8-4-23147.3800 -0.6Mhz
CC1
WARavens Roost UHF -Ravens Roost UHF - RRUWA7DMR On Network 8-3-24 and working normally440.7125 +5Mhz
CC1 - BP
WARavens Roost VHF -Ravens Roost VHF - RRVWA7DMR VHF - Very Wide Coverage both into Eastern and Western WA coverage -- Also can be standalone emergency back-up for EMCOM / Public Service146.4875 +1Mhz
CC2 - BP
WASeattle WA -Seattle Metro - SEM9-16-24: Expecting repeater to come online any day now. // Commanding view of downtown and the Puget Sound441.3250 +5Mhz
CC1
WAShelton WA -Spencer Lk - SHLN9VW Covering the Spencer & Philips Lakes area / Low level147.0200 +0.6Mhz
CC2
WAShoreline WA -Shoreline - SHR K7LFP Shoreline repeater440.1250 +5Mhz
CC1
WASpokane N. WA -Lookout Point UHF - SPL Wide area, I-90 corridor; Ritzville to Coeur d'Alene444.1500 *+5Mhz
CC1 - BP
WASpokane S. WA-UHF -Krell Hill UHF - SKUFill-in coverage // 2-10-24: Internet issues; connectivity is intermittent444.1250 *+5Mhz
CC1 - BP
WASpokane S. WA-VHF -Krell Hill VHF - SKV2-10-24: Internet issues; connectivity is intermittent Installed 08-25-18147.4125 *-1Mhz
CC1 - BP
WASpokane Valley WA -Ridgecrest VHF - SRvPair reversed on 4-16-22, now out high and low in / New Ant and Heliax @ 45ft, Wide area coverage147.4625 -1Mhz
CC1 - BP
WASultan WA -Haystack Mtn - SULHKS Affiliate wide area, I-5 corridor444.4000 +5Mhz
CC1
WATacoma WA -Ruston - TARTacoma / Seattle area fill-in (Valley Camp pair)440.7250 *+5Mhz
CC1 - BP
WATacoma WA-220 -Baldi Mtn 220 - TB2Good Coverage repeater / Anytones do well on 220 but Tx a lower power output223.8000 -1.6Mhz
CC1
WATacoma WA-UHF -Baldi Mtn UHF - TBUI-5 corridor Olympia to Seattle441.3500 +5Mhz
CC1 - BP
WATacoma WA-VHF -Baldi Mtn VHF - TBVI-5 corridor // 9-7-24: New repeater and antenna installed, coverage should be excellent now, please let us know.146.4375 +1Mhz
CC1 - BP
WATri-Cities WA-UHF -Jump off Joe UHF - TRU Wide area coverage440.7375 +5Mhz
CC1 - BP
WATri-Cities WA-VHF -Jump Off Joe VHF - TRV Very wide area coverage 146.4250 +1Mhz
CC1 - BP
WATrout Lake WA -Flattop Mtn - TFMI-84 Group Trout Lake and SR141 north of B Z Corner Installed 04-08-21443.2500 +5Mhz
CC1
WATulalip WA E -Tulalip East - TLEBack in service, both East and West442.3500 +5Mhz
CC1
WATulalip WA W -Tulalip West - TLW Back in service, both East and West444.1000 +5Mhz
CC1
WAWenatchee WA -Lower Badger - WEN Hwy 97 from Entiat to Rock Island, Hwy 2 from Cashmere to Wenatchee443.7500 *+5Mhz
CC1
WAWinthrop WA -Riser Lake - WRLMobile coverage: Lost River & Mazama, Hwy 20 east to Carlton, also north up the Chewuch Roads Installed 04-30-21145.1250 +2.8Mhz
CC3 - BP
WAYakima WA -Elephant Mtn - YAKI-82 from Ellensburg to Kennewick147.1200 +0.6Mhz
CC1 - BP
  Non-RepeatersThe MMDVM servers and other system assets are shown below to allow users to quickly check the system status from a single page. MM Servers other than Peter require permission
MMBC - MMDVM -MM Duplex (Alpha) - BC2BC-TRBO Affiliate BCTRBO TG Deck / Matrix
MMBC - MMDVM -MM Single Slot (Bravo) - BC1BC-TRBO Affiliate BCTRBO TG Deck / Matrix
MMMMDVM -Bridget (Seattle) - MMBMM Server Bridget is a single slot MMDVM server that has its Talkgroup Deck balanced for Western and Eastern WA. This is the Seattle connection to BridgetTG Deck / Matrix
MMMMDVM -Demi (Seattle) - MMDMM Demi Demi is a server for use by 2 slot devices such as MMDVM based repeaters and now 2-slot hotpspots. Most hotspots are single slot devices, and those should be connected to the other MM servers. Installed 03-17-21TG Deck / Matrix
MMMMDVM -Otis (Oregon) - MMOMM Server Otis is a single slot MMDVM server that prioritizes Oregon-based talkgroupsTG Deck / Matrix
MMMMDVM -Peter (Vancouver) - MMPMM Peter Peter is our public MMDVM single slot server with a very limited Talkgroup DeckTG Deck / Matrix
MMMMDVM -RexX (Oregon) - MMRMM RexX RexX is our server for use by 2 slot devices such as MMDVM based repeaters and now 2-slot hotpspots. Most hotspots are single slot devices, and those should be connected to the other MM servers.TG Deck / Matrix
MMMMDVM -Suzy (Seattle) - MMSMM Server Suzy is a single slot MMDVM that has both Western and Eastern WA servers that both connect to the same c-bridge manager. This is the Suzy Seattle connection.TG Deck / Matrix
MMMMDVM -Ted (Seattle) - MMTMM Ted W7NCX Ted is a server for use by 2 slot devices such as MMDVM based repeaters and now 2-slot hotpspots. Most hotspots are single slot devices, and those should be connected to the other MM servers. Installed 06-10-22TG Deck / Matrix
MMMMDVM -Wes (Seattle) - MMWMM Server Wes is a single slot MMDVM server that favors western WashingtonTG Deck / Matrix
Legend and notes:

Repeater/MM connected to cBridge.
Repeater/MM not connected to cBridge. Repeater RF may be up.
Repeater/MM intermittent connection to cBridge - yellow - connecting, disconnecting, or unstable
External device - Status unknown. Normal condition for the Haystack Repeater
Repeater/MM Status unknown. Status monitoring may be out of order.
  • Status monitoring is limited to network connectivity of the device.
  • Repeater RF status is always unknown. Please send reports to tech@pnwdigital.net or the repeater owner/trustee.
  • Frequency shown is user's radio Rx.
  • Offset is user's radio Tx. Hover over offset for Tx frequency.
  • Grey shading indicates not online; pending install, in planning, repair, delayed, or shelved
  • Click on color code link to contact repeater owner
  • Click on BP link for repeater policies/best practices
  • * next to frequency indicates duplicated/reused Frequency/color code
  • Heatmaps and status are approximate only
